S234AB

S234AB; Skantic Radio AB, (ID = 1286549) Radio S234AB; Skantic Radio AB, (ID = 1286550) Radio
S234AB; Skantic Radio AB, (ID = 1286551) Radio S234AB; Skantic Radio AB, (ID = 1286552) Radio
Use red slider bar for more.
S234AB; Skantic Radio AB, (ID = 1286549) Radio
Skantic Radio AB,: S234AB [Radio] ID = 1286549 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model S234AB, Skantic Radio AB, Stockholm

Country:  Sweden
Manufacturer / Brand:  Skantic Radio AB, Stockholm
alternative name

Skandinaviska Radio AB
Year: 1955 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: DK92 DF91 DF91 DAF91 DL94
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Batteries (any type) / 110-250 / 90 & 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: S234AB - Skantic Radio AB, Stockholm
Material Wooden case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 370 x 260 x 170 mm / 14.6 x 10.2 x 6.7 inch
Net weight (2.2 lb = 1 kg) 5.6 kg / 12 lb 5.4 oz (12.335 lb)

Model page created by Aarre Iitti. See "Data change" for further contributors.
