511P
Sobell Ind., Slough
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Sobell Ind., Slough
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 144138
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Number of Transistors
- Semiconductors
- Selenium-Rectifier
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: 511P - Sobell Ind., Slough
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Same chassis in models 511W (Walnut), 511AG (Console Auto Radiogram), 511TAG (Table Auto Radiogram).
- Price in first year of sale
- 14.00 GBP
- Source of data
- -- Schematic
- Circuit diagram reference
- Radio and TV Servicing books (R&TVS) book
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1016 dated October 27 1951)
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
