N179

N179; S.P. Radio A/S; (ID = 704240) Power-S N179; S.P. Radio A/S; (ID = 704241) Power-S
N179; S.P. Radio A/S; (ID = 704242) Power-S
Use red slider bar for more.
N179; S.P. Radio A/S; (ID = 704240) Power-S
S.P. Radio A/S;: N179 [Power-S] ID = 704240 664x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model N179, S.P. Radio A/S; Aalborg

Country:  Denmark
Manufacturer / Brand:  S.P. Radio A/S; Aalborg
Brand

Sailor
Year: 1972 ? Category: Power supply/conditioner or battery or charger
Semiconductors (the count is only for transistors) 2:
Wave bands - without
Details
Power type and voltage Direct Current supply (DC) / 24 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: N179 - S.P. Radio A/S; Aalborg
Material Metal case
Dimensions (WHD) 150 x 260 x 250 mm / 5.9 x 10.2 x 9.8 inch
Notes Matching power supply for transmitter Sailor T128 and receiver Sailor R103, R104, R105 and R106. Input voltage 24VDC. Output voltages are: 900V anode voltage to PA-tubes. 300V screen grid voltage to PA-tubes and anode voltage to driver. -84V negative grid bias. 24VDC for filament voltage transmitter.

Alimentatore da abbinare al trasmettitore T128 e ricevitori R103, R104, R105, R106 Sailor. Tensione nominale di ingresso 24V DC. Uscite: 900V anodica, 300V griglia schermo, -84V bias, 24V filamenti.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Literature/Schematics (1) Manuale d'uso in dotazione.

Model page created by Enrico Puccini. See "Data change" for further contributors.
