Radiola 373 LV

Radiola 373 LV; SRA Svenska (ID = 1956088) Radio Radiola 373 LV; SRA Svenska (ID = 1956089) Radio
Radiola 373 LV; SRA Svenska (ID = 1956090) Radio Radiola 373 LV; SRA Svenska (ID = 1956091) Radio
Radiola 373 LV; SRA Svenska (ID = 1956092) Radio Radiola 373 LV; SRA Svenska (ID = 1956093) Radio
Radiola 373 LV; SRA Svenska (ID = 1956094) Radio Radiola 373 LV; SRA Svenska (ID = 1956095) Radio
Radiola 373 LV; SRA Svenska (ID = 1956097) Radio
Use red slider bar for more.
Radiola 373 LV; SRA Svenska (ID = 1956088) Radio
SRA Svenska: Radiola 373 LV [Radio] ID = 1956088 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola 373 LV, SRA Svenska Radioaktiebolaget; Stockholm

Country:  Sweden
Manufacturer / Brand:  SRA Svenska Radioaktiebolaget; Stockholm
Brand

Radiola
Year: 1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: EK2 EF5 EBC3 CL4 CY2
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 120; 130; 150; 200; 220; 245 Volt
Loudspeaker -Loudspeaker incorporated, but system not known. / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Radiola 373 LV - SRA Svenska Radioaktiebolaget;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 432 x 298 x 242 mm / 17 x 11.7 x 9.5 inch
Price in first year of sale 245.00 SEK
Source of data - - Manufacturers Literature

Model page created by Anders Söderström. See "Data change" for further contributors.



All listed radios etc. from SRA Svenska Radioaktiebolaget; Stockholm
Here you find 268 models, 158 with images and 158 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
