Radiola 398 LV
Use red slider bar for more.
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
Brand
|
Radiola | ||||
|---|---|---|---|---|---|
| Year: 1939 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: ECH3 EF5 EBC3 EM1 CL4 CY2 |
| Main principle | Superheterodyne (common); ZF/IF 144 kHz |
|---|---|
| Wave bands | Broadcast, Long Wave and Short Wave. |
| Details | Changer (Record changer) |
| Power type and voltage | AC/DC-set / 110-245 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | 4 W (unknown quality) |
| from Radiomuseum.org | Model: Radiola 398 LV - SRA Svenska Radioaktiebolaget; |
| Material | Wooden case |
| Shape | Console, Lowboy (legs < 50 %). |
| Dimensions (WHD) | 605 x 900 x 465 mm / 23.8 x 35.4 x 18.3 inch |
| Notes |
See also 394LV for circuit diagram. |
| Net weight (2.2 lb = 1 kg) | 44 kg / 96 lb 14.7 oz (96.916 lb) |
| Price in first year of sale | 738.00 SEK |
| Source of data | - - Manufacturers Literature |
Model page created by Anders Söderström. See "Data change" for further contributors.
