Radiola 398 V

Radiola 398 V; SRA Svenska (ID = 1618540) Radio

Radiola 398 V; SRA Svenska (ID = 1618541) Radio

Radiola 398 V; SRA Svenska (ID = 1618538) Radio

Radiola 398 V; SRA Svenska (ID = 1618539) Radio
Use red slider bar for more.
Radiola 398 V; SRA Svenska (ID = 1618540) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Sweden
Manufacturer / Brand:  SRA Svenska Radioaktiebolaget; Stockholm
Brand

Radiola
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH3 EF5 EBC3 EM1 EL3 AZ1
Main principle Superheterodyne (common); ZF/IF 144 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Radiola 398 V - SRA Svenska Radioaktiebolaget;
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 605 x 900 x 465 mm / 23.8 x 35.4 x 18.3 inch
Notes

Price including record changer.

Net weight (2.2 lb = 1 kg) 44 kg / 96 lb 14.7 oz (96.916 lb)
Price in first year of sale 710.00 SEK
Source of data - - Manufacturers Literature

Model page created by Anders Söderström. See "Data change" for further contributors.
