W4

W4; Stassfurter Licht- (ID = 269361) Radio
W4; Stassfurter Licht- (ID = 802595) Radio W4; Stassfurter Licht- (ID = 16545) Radio
W4; Stassfurter Licht- (ID = 802594) Radio W4; Stassfurter Licht- (ID = 802596) Radio
W4; Stassfurter Licht- (ID = 1133962) Radio
Use red slider bar for more.
W4; Stassfurter Licht- (ID = 802595) Radio
Stassfurter Licht-: W4 [Radio] ID = 802595 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model W4, Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter)

Country:  Germany
Manufacturer / Brand:  Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter)
Year: 1927–1930 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RE084 RE054 RE054 RE134
Main principle TRF with regeneration; 3 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: W4 - Stassfurter Licht- und
Material Wooden case
Dimensions (WHD) 370 x 230 x 200 mm / 14.6 x 9.1 x 7.9 inch
Notes Primär-Empfänger; 200-3000 m [560].
Price in first year of sale 138.00 RM +
Source of data Arlt's grosser Radiokatalog 1930 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Röhren in FS-Bestückungstabellen
Mentioned in Der Radio-Händler / Radio-Fernseh-Händler (ab Aug. 1951, H.15) (2920)
