Berlin EZ80
Use red slider bar for more.
Stern-Radio Berlin,: Berlin [Radio] ID = 335268 933x634
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Phonetika Radio Berlin, VEB; Berlin, (Ostd.) | ||||
|---|---|---|---|---|---|
| Year: 1956/1957 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 7: ECC81 ECH81 EF85 EABC80 EM11 EL84 EZ80 |
| Main principle | Superheterodyne (common); ZF/IF 468 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 9 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, more than 2 x SW plus FM or UHF. |
| Details | |
| Power type and voltage | 110, 127, 220, 240 Volt |
| Loudspeaker | 3 Loudspeakers |
| Power out | 3 W (unknown quality) |
| from Radiomuseum.org | Model: Berlin [EZ80] - Stern-Radio Berlin, VEB, RFT, |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 610 x 395 x 285 mm / 24 x 15.6 x 11.2 inch |
| Notes | Bandspreizung bei Kurzwelle auf 3 Bereiche, stetige Bandbreiteneinstellung wirksam auf AM Bereichen |
| Net weight (2.2 lb = 1 kg) | 15 kg / 33 lb 0.6 oz (33.04 lb) |
| External source of data | E. Erb 3-907007-36-0 |
| Source of data | Radiokatalog Band 2, Ernst Erb |
| Literature/Schematics (1) | -- Original-techn. papers. |
