Ilmenau 4880; Stern-Radio (ID = 1054462) Radio
Stern-Radio: Ilmenau 4880 [Radio] ID = 1054462 933x677
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ilmenau 4880, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EBF89 EBF89 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 180; 200; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Ilmenau 4880 - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 440 x 280 x 220 mm / 17.3 x 11 x 8.7 inch
Notes Chassis entspricht "Ilmenau 4950", Gehäuse Edelholzfurnier poliert.
Net weight (2.2 lb = 1 kg) 6.7 kg / 14 lb 12.1 oz (14.758 lb)
Price in first year of sale 410.00 DM
Collectors' prices
Source of data -- Collector info (Sammler)
Mentioned in -- Original-techn. papers.

Model page created by Lutz Höll. See "Data change" for further contributors.
