Stern-Radio: Oberhof 43/52 GWH [Radio] ID = 2213567 1000x772

Select picture or schematic to display from thumbnails on the right and click for download.

For model Oberhof 43/52 GWH, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:

Germany

Manufacturer / Brand:

Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Year: 1952/1953

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

2: UCH11 or UCH171 or UCH81 UEL51 or UEL171

Semiconductors (the count is only for transistors)

Tr.Gl.=Metal-rectif.

Main principle	to an article Super-Heterodyne (Super in general); ZF/IF 473 kHz; Reaction
Tuned circuits	4 AM circuit(s)
Wave bands	Broadcast only (MW).
Details
Power type and voltage	AC/DC-set / 220 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org	Model: Oberhof 43/52 GWH - Stern-Radio Sonneberg, VEB,
Material	Wooden case
Shape	Tablemodel, with any shape - general.
Dimensions (WHD)	370 x 250 x 165 mm / 14.6 x 9.8 x 6.5 inch
Notes	Rückk. [555309]. Bei der einfachen Suche bitte nie den Hersteller/Marke eingeben. Hier haben wir dies nur zu dem Zweck mit einbezogen, dass Sie das wissen können (Blaue Info-Knöpfe klicken!). VEB STern Radio Sonneberg, Modell Oberhof 43/52 GW schreiben wir sonst nur Oberhof 43/52GW oder 43/52 GW ohne VEB Stern Radio Sonneberg. Parallelfertigung der Varianten GWH (Holz) und GWP (Pressstoff). Anfangs mit Spangeflecht als LS-Abdeckung, später Stoff. Variometer-Abstimmung. Schallwand Sperrholz, später Presspappe. Ende 1953 Fertigung nach MGW Zwönitz verlagert (siehe dort).
Net weight (2.2 lb = 1 kg)	5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale	170.00 DM
Collectors' prices
External source of data	E. Erb 3-907007-36-0
Source of data	Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967 / Radiokatalog Band 2, Ernst Erb
Mentioned in	Funk-Technik (FT) (5309)
Literature/Schematics (1)	-- Original-techn. papers.

All listed radios etc. from Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Here you find 379 models, 300 with images and 277 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Anatoly Yasinsky (BY)

Collection of Werner Speidel † 2012 (D)

Collection of Helmut Ebert (D)

Collection of Piotr Jachymczyk (PL)

Collection of Klaus Bayer (D)

Collection of Reinhard Hopfe (D)

Collection of Werner Wiemer (D)

Collection of Eddy Perlick (D)

Collection of Andreas Reuther (D)

Collection of Jörg Schäfer (D)

Forum contributions about this model

Stern-Radio: Oberhof 43/52 GWH

Threads: 2 | Posts: 2

Hits: 1415 Replies: 0

stern-sonn: 43/52 GWH; Oberhof

Martin Schmidt2
07.Jan.08

stern-sonn: 43/52 GWH; Oberhof

Hallo,

welche Lautsprecherbespannung ist bei diesem Gerät richtig? Suche den Originalstoff..

Gruss Martin

Hits: 1449 Replies: 0 rfst: 43/52GW (neu); Oberhof
Mario Tieke 08.Nov.03	1 rfst: 43/52GW (neu); Oberhof Abweichung in der Röhrenbestückung siehe auch 43/52GW (alt)
