Stern-Radio: Tucana 5530 [Radio] ID = 2659969 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1967 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: ECC85 ECH81 EAF801 ECL86 EM84 | ||||
|---|---|---|---|---|---|
| Semiconductors (the count is only for transistors) | Tr.Gl.=Metal-rectif. |
| Main principle | Superheterodyne (common); ZF/IF 455/10700 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 220; 240 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | 2.7 W (unknown quality) |
| from Radiomuseum.org | Model: Tucana 5530 - Stern-Radio Sonneberg, VEB, |
| Material | Wooden case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 704 x 224 x 214 mm / 27.7 x 8.8 x 8.4 inch |
| Notes | Tucana 5530 mit einem UKW- Bereich bis 104 MHz, Exportgerät. Diodenbuchse, Anschlußbuchse für einen Zweitlautsprecher. |
| Net weight (2.2 lb = 1 kg) | 8.5 kg / 18 lb 11.6 oz (18.722 lb) |
| Source of data | - - Manufacturers Literature |
| Literature/Schematics (1) | Service- DVD vom Funkverlag B. Hein. |
