Tucana 5720

Tucana 5720; Stern-Radio (ID = 798171) Radio

Tucana 5720; Stern-Radio (ID = 798845) Radio

Tucana 5720; Stern-Radio (ID = 798846) Radio

Tucana 5720; Stern-Radio (ID = 798848) Radio

Tucana 5720; Stern-Radio (ID = 798857) Radio

Tucana 5720; Stern-Radio (ID = 798851) Radio

Tucana 5720; Stern-Radio (ID = 798853) Radio

Tucana 5720; Stern-Radio (ID = 798850) Radio

Tucana 5720; Stern-Radio (ID = 798855) Radio

Tucana 5720; Stern-Radio (ID = 798865) Radio
Tucana 5720; Stern-Radio (ID = 1064670) Radio Tucana 5720; Stern-Radio (ID = 1064671) Radio
Tucana 5720; Stern-Radio (ID = 1064672) Radio
Use red slider bar for more.
Tucana 5720; Stern-Radio (ID = 1064670) Radio
Stern-Radio: Tucana 5720 [Radio] ID = 1064670 933x324
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tucana 5720, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG:
Tucana 5720 Frontansicht

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EAF801 ECL86 EM84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.7 W (unknown quality)
from Radiomuseum.org Model: Tucana 5720 - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 704 x 224 x 214 mm / 27.7 x 8.8 x 8.4 inch
Notes Tucana 5720, ein Gerät für den DDR- Binnenmarkt mit einem UKW- Bereich bis 100 MHz. Kurzwelle von 5,9 bis 15,55 MHz. Anschlüsse für TA/ TB und für einen Zweitlautsprecher. Getrennter Antrieb für AM/ FM- Abstimmung. Eingebaut im edelholzfurniertem Holzgehäuse im nordischen Stil.
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 440.00 DM
Source of data - - Manufacturers Literature
Literature/Schematics (1) Service- DVD vom Funkverlag B. Hein.

Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.



All listed radios etc. from Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Here you find 379 models, 300 with images and 277 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
