Wartburg 5000 A; Stern-Radio (ID = 2327446) Radio
Stern-Radio: Wartburg 5000 A [Radio] ID = 2327446 1070x536
Select picture or schematic to display from thumbnails on the right and click for download.
For model Wartburg 5000 A, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH81 EBF89 EBF89 EL84 EM84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 180; 200; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.7 W (unknown quality)
from Radiomuseum.org Model: Wartburg 5000 A - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 520 x 280 x 220 mm / 20.5 x 11 x 8.7 inch
Notes Wartburg 5000A, ein Exportsuper mit den Kurzwellenbereichen K1 von 9,0 bis 22,0 MHz und K2 von 3,15 bis 7,4 MHz.
Literature/Schematics (1) Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967 (Service- DVD vom Funkverlag B. Hein)

Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.



All listed radios etc. from Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Here you find 379 models, 300 with images and 277 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
