Stassfurt Admiral RFT-Super 10E152; Stern-Radio Staßfurt (ID = 268327) Radio
Stern-Radio Staßfurt: Stassfurt Admiral RFT-Super 10E152 [Radio] ID = 268327 842x595
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stassfurt Admiral RFT-Super 10E152, Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...

Country:  Germany
Manufacturer / Brand:  Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...
alternative name

Fernsehgerätewerk Staßfurt
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: EC92 EC92 ECH81 EF85 EM11 EABC80 ECC81 EL84 EL84 EYY13
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110, 127, 220, 240 Volt
Loudspeaker 3 Loudspeakers / Ø 24.5 cm = 9.6 inch
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Stassfurt Admiral RFT-Super 10E152 - Stern-Radio Staßfurt, VEB, RFT
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 660 x 450 x 310 mm / 26 x 17.7 x 12.2 inch
Notes

Anschlüsse für TA und Außenlautsprecher, Gehäuselautsprecher abschaltbar , getrennte Höhen- und Tiefenregelung, 3-D-Ton

Der Empfänger Admiral 10E152 von Stern Radio Staßfurt (VEB) kann an der Gerätefront (Schallwand) die Bezeichnung Stassfurt tragen.
Um die Auffindbarkeit zu verbessern, führen wir beide Bezeichnungen (Admiral bzw. Stassfurt) im Modellnamen.

Net weight (2.2 lb = 1 kg) 25.5 kg / 56 lb 2.7 oz (56.167 lb)
Price in first year of sale 816.00 DM
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Radio und Fernsehen 6/1956
Literature/Schematics (1) -- Original-techn. papers. (Gebrauchswaren-Katalog Rundfunk-Fernsehen, Leipzig 1954)

Model page created by Frank Blöhbaum. See "Data change" for further contributors.



All listed radios etc. from Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...
Here you find 396 models, 314 with images and 309 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
