9E95
Stern-Radio Staßfurt: 9E95 [Radio] ID = 1236989 933x579
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Fernsehgerätewerk Staßfurt | ||||
|---|---|---|---|---|---|
| Year: 1952/1953 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 12: 6SH7_DDR ECH11 6SH7_DDR 6SH7_DDR EM11 6H6_DDR EBF11 EL12 AZ12 EF14 EF14 EZ11 |
| Main principle | Superheterodyne (common); ZF/IF 468 kHz |
|---|---|
| Tuned circuits | 9 AM circuit(s) 9 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, more than 2 x SW plus FM or UHF. |
| Details | Record Player + Tape Recorder |
| Power type and voltage | Alternating Current supply (AC) / 110-240 Volt |
| Loudspeaker | 2 Loudspeakers |
| Power out | |
| from Radiomuseum.org | Model: 9E95 - Stern-Radio Staßfurt, VEB, RFT |
| Material | Wooden case |
| Shape | Console with any shape - in general |
| Dimensions (WHD) | 1370 x 900 x 490 mm / 53.9 x 35.4 x 19.3 inch |
| Notes | 3x KW, Chassis 9E91 = abgest. Bandfiltereingang. Mit Magnettongerät MTG22 (2xEF14+EZ11) plus Plattenspieleraufsatz mit magn. Tonabn. für 78 U (Stassfurt). Daten von Frank Blöhbaum. |
| Net weight (2.2 lb = 1 kg) | 115 kg / 253 lb 4.9 oz (253.304 lb) |
| Price in first year of sale | 1'200.00 DM |
| Source of data | Radiokatalog Band 2, Ernst Erb |
| Mentioned in | Deutsche Funk-Technik (Deutsche Funktechnik) [DDR] (5309) |
