Staßfurt (Stassfurt) 62 Ch= 1182

Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 107265) Radio
Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 848043) Radio Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 663000) Radio
Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 848045) Radio Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 663002) Radio
Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 140826) Radio Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 417674) Radio
Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 417675) Radio Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 417676) Radio
Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 417677) Radio Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 417680) Radio
Use red slider bar for more.
Staßfurt 62 Ch= 1182; Stern-Radio Staßfurt (ID = 848043) Radio
Stern-Radio Staßfurt: Staßfurt 62 Ch= 1182 [Radio] ID = 848043 819x614
Select picture or schematic to display from thumbnails on the right and click for download.
For model Staßfurt (Stassfurt) 62 Ch= 1182, Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...

Country:  Germany
Manufacturer / Brand:  Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...
alternative name

Fernsehgerätewerk Staßfurt
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCC85 UCH81 UF89 UF89 UM80 UABC80 UL84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Superheterodyne (common); ZF/IF 453/10700 kHz
Tuned circuits 8 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Staßfurt 62 Ch= 1182 - Stern-Radio Staßfurt, VEB, RFT
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 670 x 410 x 280 mm / 26.4 x 16.1 x 11 inch
Notes Letztes Radio aus Stassfurt, Firmierung bereits als Fernsehgerätewerke Stassfurt. Übernahme des Dominante A122 aus Funkwerk Dresden (Chassisnummer 1132). Das Chassis erhält nun die Nummer 1182.
Drehbare FA; 5 Klangregistertasten.
Net weight (2.2 lb = 1 kg) 14 kg / 30 lb 13.4 oz (30.837 lb)
Price in first year of sale 610.00 DM
Source of data Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967 / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Collector info (Sammler) (Funkverlag Hein, Service-CD)
Documents regarding this model
  Bedienungsanweisung 1962 511 KB

Model page created by Wolfgang Eckardt. See "Data change" for further contributors.



All listed radios etc. from Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...
Here you find 396 models, 314 with images and 309 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
