Ultra IV (4)
Südfunk-Apparatebau, Dr. Ing. Robert Ott; Stuttgart
- Country
- Germany
- Manufacturer / Brand
- Südfunk-Apparatebau, Dr. Ing. Robert Ott; Stuttgart
- Year
- 1950 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 74975
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Ultra IV - Südfunk-Apparatebau, Dr. Ing.
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 580 x 380 x 220 mm / 22.8 x 15 x 8.7 inch
- Notes
- Bereich K1 = 6,5 - 20 MHz, dito K2 = 1,65 - 6,5 MHz.
- Net weight (2.2 lb = 1 kg)
- 12 kg / 26 lb 6.9 oz (26.432 lb)
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Author
- Model page created by Ingo Gantenbrink. See "Data change" for further contributors.
