529

529; Superla - Cresa; (ID = 53768) Radio
529; Superla - Cresa; (ID = 133123) Radio 529; Superla - Cresa; (ID = 2078892) Radio
529; Superla - Cresa; (ID = 2078893) Radio 529; Superla - Cresa; (ID = 2078894) Radio
Use red slider bar for more.
529; Superla - Cresa; (ID = 133123) Radio
Superla - Cresa;: 529 [Radio] ID = 133123 592x484
Select picture or schematic to display from thumbnails on the right and click for download.
For model 529, Superla - Cresa; Modena

Country:  Italy
Manufacturer / Brand:  Superla - Cresa; Modena
alternative name

Cresa Radio; Modena
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8 6K7 6Q7 6F6 80
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110-235 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 529 - Superla - Cresa; Modena
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 510 x 390 x 280 mm / 20.1 x 15.4 x 11 inch
Source of data Guida Pratica Antique Radio (1) 1999
Literature/Schematics (1) Il Radio Libro (E.D. Ravalico) Edizioni Hoepli

Model page created by Alessandro De Poi. See "Data change" for further contributors.
