VV-662; Tallinn Punane RET (ID = 1597648) Radio
Tallinn Punane RET: VV-662 [Radio] ID = 1597648 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model VV-662, Tallinn Punane RET Radio Works

Country:  Estonia (Eesti, Tallinn)
Manufacturer / Brand:  Tallinn Punane RET Radio Works
Year: 1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6А7 6К7 6Е5С 6Г7 6Ф6С 5Ц4С
Main principle Super-Heterodyne (Super in general); ZF/IF 465 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110/127/220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: VV-662 - Tallinn Punane RET Radio Works
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 610 x 260 x 340 mm / 24 x 10.2 x 13.4 inch
Notes shortwave bands 4 - 22,2 MHz (16,1 - 75 m).
Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
External source of data E.A.Levitin "Spravocnik po radiovesciatelnym prijomnikam", Moscow 1960

Model page created by Zenonas Langaitis. See "Data change" for further contributors.



All listed radios etc. from Tallinn Punane RET Radio Works
Here you find 21 models, 21 with images and 15 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
