VV-662 6SA7, first edition

VV-662; Tallinn Punane RET (ID = 583263) Radio

VV-662; Tallinn Punane RET (ID = 583264) Radio

VV-662; Tallinn Punane RET (ID = 583265) Radio
VV-662; Tallinn Punane RET (ID = 583258) Radio VV-662; Tallinn Punane RET (ID = 583260) Radio
VV-662; Tallinn Punane RET (ID = 583259) Radio VV-662; Tallinn Punane RET (ID = 283058) Radio
VV-662; Tallinn Punane RET (ID = 283059) Radio VV-662; Tallinn Punane RET (ID = 838244) Radio
VV-662; Tallinn Punane RET (ID = 838245) Radio VV-662; Tallinn Punane RET (ID = 838246) Radio
Use red slider bar for more.
VV-662; Tallinn Punane RET (ID = 583258) Radio
Tallinn Punane RET: VV-662 [Radio] ID = 583258 853x559
Select picture or schematic to display from thumbnails on the right and click for download.
For model VV-662 6SA7, first edition, Tallinn Punane RET Radio Works:
Kaunas Lithuania

Country:  Estonia (Eesti, Tallinn)
Manufacturer / Brand:  Tallinn Punane RET Radio Works
Year: 1946–1951 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SA7 or 6А10 6К7 6Е5С 6Г7 6Ф6С 5Ц4С
Main principle Super-Heterodyne (Super in general); ZF/IF 625 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: VV-662 [6SA7, first edition] - Tallinn Punane RET Radio Works
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 610 x 260 x 340 mm / 24 x 10.2 x 13.4 inch
Notes Probably developed in 1940, before 1941(WW2)too.
Shortwave bands 4 - 22,2 MHz (16,1 - 75 m).
Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
Mentioned in -- Collector info (Sammler)
Literature/Schematics (1) -- Schematic

Model page created by Zenonas Langaitis. See "Data change" for further contributors.
