Tape Recorder 2F
Tandberg Radio; Oslo
- Country
- Norway
- Manufacturer / Brand
- Tandberg Radio; Oslo
- Year
- 1959 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 158775
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120; 220 - 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: Tape Recorder 2F - Tandberg Radio; Oslo
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 400 x 190 x 330 mm / 15.7 x 7.5 x 13 inch
- Notes
-
The Tandberg Model 2F is an AC operated two speed tape recorder and has relays for instant start, stop, and rewind.
The weight is taken with the tape recorder in the carrying case.
The measures are the outside dimensions of the carrying case, excluding the carrying handle, the latches and the feet.
- Net weight (2.2 lb = 1 kg)
- 11.7 kg / 25 lb 12.3 oz (25.771 lb)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 3-59, Set 433, Folder 13)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
