For model 40B, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1929–1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RES044 or RES094 RE084 RE054 RE134 or RE604
Main principle TRF with regeneration; 1 Special; 2 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 200+4 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: 40B - Telefunken Deutschland TFK,
Material Bakelite case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 520 x 280 x 220 mm / 20.5 x 11 x 8.7 inch
Notes 4farb.Trommelsk. [569]
Price in first year of sale 320.00 RM
Source of data Arlt's grosser Radiokatalog 1930 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Mentioned in Der Radio-Händler / Radio-Fernseh-Händler (ab Aug. 1951, H.15) (2920)
Picture reference Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
