5U38 / T6515 GWK

5U38 / T6515 GWK; Telefunken; Wien (ID = 1373683) Radio 5U38 / T6515 GWK; Telefunken; Wien (ID = 1373684) Radio
5U38 / T6515 GWK; Telefunken; Wien (ID = 1373686) Radio 5U38 / T6515 GWK; Telefunken; Wien (ID = 1373687) Radio
5U38 / T6515 GWK; Telefunken; Wien (ID = 1373688) Radio 5U38 / T6515 GWK; Telefunken; Wien (ID = 1373689) Radio
5U38 / T6515 GWK; Telefunken; Wien (ID = 1373692) Radio 5U38 / T6515 GWK; Telefunken; Wien (ID = 1373693) Radio
5U38 / T6515 GWK; Telefunken; Wien (ID = 1373694) Radio 5U38 / T6515 GWK; Telefunken; Wien (ID = 1373695) Radio
Use red slider bar for more.
5U38 / T6515 GWK; Telefunken; Wien (ID = 1373683) Radio
Telefunken; Wien: 5U38 / T6515 GWK [Radio] ID = 1373683 933x461
Select picture or schematic to display from thumbnails on the right and click for download.
For model 5U38 / T6515 GWK, Telefunken; Wien:
Thanks for Mr.Sik Béla, Hungary, Budapest and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Austria
Manufacturer / Brand:  Telefunken; Wien
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: CK1 CF7 CBC1 CL4 CY1
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 120; 150; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
Power out
from Radiomuseum.org Model: 5U38 / T6515 GWK - Telefunken; Wien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 610 x 305 x 240 mm / 24 x 12 x 9.4 inch
Notes

Telefunken verwendet für das Modell 5U38 einen ungewöhnlichen Typschlüssel.
Siehe auch das Wechselstrom-Modell 5W38 mit anderer Gehäuseausführung.

Net weight (2.2 lb = 1 kg) 10.7 kg / 23 lb 9.1 oz (23.568 lb)

Model page created by Simeon Nikolov. See "Data change" for further contributors.
