For model Adagio 53W, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC81 ECH81 EF41 EABC80 EM35 EL41
Semiconductors (the count is only for transistors) B250C75
Main principle Super-Heterodyne (Super in general); ZF/IF 452/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: Adagio 53W - Telefunken Deutschland TFK,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 540 x 360 x 240 mm / 21.3 x 14.2 x 9.4 inch
Net weight (2.2 lb = 1 kg) 10.1 kg / 22 lb 3.9 oz (22.247 lb)
Price in first year of sale 299.00 DM
Collectors' prices
External source of data Erb
Source of data Kat.d.Rundf.GrossH.1953/54
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Here you find 3391 models, 2949 with images and 1939 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Telefunken: Adagio 53W
Threads: 1 | Posts: 1
Hits: 354     Replies: 0
telefunken: Abgleichtabelle für Adagio 53W
Heinz LUCAS
11.Apr.18
  1

Werte Mitglieder,

die fehlende Abgleichtabelle für dieses Modell ist in Modell Adagio 53GW zu finden.

Es grüßt

Heinz Lucas
