Cicerone UB1764
Telefunken Radiotécnica Ibérica; Getafe
- Country
- Spain
- Manufacturer / Brand
- Telefunken Radiotécnica Ibérica; Getafe
- Year
- 1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 164223
Anuncio ABC diciembre 1954
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Main principle
- Superhet with RF-stage
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Line / Batteries (any type) / AC: 125; DC: 110 / 9 & 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Cicerone UB1764 - Telefunken Radiotécnica
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 350 x 280 x 155 mm / 13.8 x 11 x 6.1 inch
- Notes
-
Telefunken Radiotécnica Ibérica; Cicerone UB-1764
Peso incluidas las baterías (6,6 kg). Recargador de baterías incorporado.
En los anuncios a partir de junio de 1955 aparece con un nuevo precio de 1995 pts.
- Net weight (2.2 lb = 1 kg)
- 6.6 kg / 14 lb 8.6 oz (14.537 lb)
- Price in first year of sale
- 3,485.00 ESP
- Mentioned in
- -- Original prospect or advert (Novedades Científicas Telefunken 1903-1954)
- Literature/Schematics (4)
- La Vanguardia Española octubre 1954; ABC diciembre 1954
- Author
- Model page created by Jose Antonio Gonzalez-Ruiz. See "Data change" for further contributors.
