Conquistador 654AC

Conquistador 654AC; Telefunken (ID = 284196) Radio

Conquistador 654AC; Telefunken (ID = 284197) Radio

Conquistador 654AC; Telefunken (ID = 284198) Radio
Conquistador 654AC; Telefunken (ID = 2416635) Radio Conquistador 654AC; Telefunken (ID = 312333) Radio
Conquistador 654AC; Telefunken (ID = 962855) Radio Conquistador 654AC; Telefunken (ID = 2416177) Radio
Conquistador 654AC; Telefunken (ID = 962857) Radio Conquistador 654AC; Telefunken (ID = 2416176) Radio
Use red slider bar for more.
Conquistador 654AC; Telefunken (ID = 2416635) Radio
Telefunken: Conquistador 654AC [Radio] ID = 2416635 1280x720
Select picture or schematic to display from thumbnails on the right and click for download.
For model Conquistador 654AC, Telefunken Radiotécnica Ibérica; Getafe

Country:  Spain
Manufacturer / Brand:  Telefunken Radiotécnica Ibérica; Getafe
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH3 ECF1 CBL6 CY2
Main principle Superheterodyne (common); ZF/IF 468 kHz; 2 AF stage(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 127 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Conquistador 654AC - Telefunken Radiotécnica
Material Bakelite case
Notes En un anuncio decia asi: "En viajes podrá llevar cómodamente su CONQUISTADOR en la maleta-estuche que le ofrecemos. Pesetas 150"
Price in first year of sale 2'052.00 ESP
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
