D779 WK trop Hi-Fi-System

Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

Data
Forum
Pictures
Collections

  • Year
  • 1958 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 341620

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superhet with RF-stage; Export model
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: D779 WK trop Hi-Fi-System - Telefunken Deutschland TFK,
  • Shape
  • Tablemodel with Push Buttons.
  • Notes

  • Telefunken D779 WK trop is a tropicalized export model.

    Wave bands:

    • K1/SW1 = 17.5 - 26.5 MHz
    • K2/SW2 = 10.8 - 17.8 MHz
    • K3/SW3 = 4.5 - 10.8 MHz
    • K4/SW4 = 1.6 - 4.8 MHz
    • M/MW = 510 - 1620 kHz

    Receiver can be powered from a storage battery by using an additional plug-in inverter unit (vibrator).
