Jubilate 205

Jubilate 205; Telefunken Italia, (ID = 285566) Radio

Jubilate 205; Telefunken Italia, (ID = 285568) Radio

Jubilate 205; Telefunken Italia, (ID = 1947090) Radio

Jubilate 205; Telefunken Italia, (ID = 1947117) Radio

Jubilate 205; Telefunken Italia, (ID = 1947118) Radio

Jubilate 205; Telefunken Italia, (ID = 1947119) Radio

Jubilate 205; Telefunken Italia, (ID = 1947120) Radio
Jubilate 205; Telefunken Italia, (ID = 1792962) Radio Jubilate 205; Telefunken Italia, (ID = 274282) Radio
Jubilate 205; Telefunken Italia, (ID = 274280) Radio Jubilate 205; Telefunken Italia, (ID = 274281) Radio
Jubilate 205; Telefunken Italia, (ID = 274279) Radio Jubilate 205; Telefunken Italia, (ID = 1792963) Radio
Jubilate 205; Telefunken Italia, (ID = 1792964) Radio Jubilate 205; Telefunken Italia, (ID = 1792966) Radio
Use red slider bar for more.
Jubilate 205; Telefunken Italia, (ID = 1792962) Radio
Telefunken Italia,: Jubilate 205 [Radio] ID = 1792962 1176x721
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jubilate 205, Telefunken Italia, Milano:
Ebay auction by user dewsthedew 181589713600

Country:  Italy
Manufacturer / Brand:  Telefunken Italia, Milano
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 117; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.8 W (unknown quality)
from Radiomuseum.org Model: Jubilate 205 - Telefunken Italia, Milano
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 360 x 200 x 160 mm / 14.2 x 7.9 x 6.3 inch
Notes Transistoren: AF106, AF121, AF138, AF137, AF121, AC122, AC116, AC117, AC175; Dioden: 5× AA112, A121, TZ7,5.
Net weight (2.2 lb = 1 kg) 3.4 kg / 7 lb 7.8 oz (7.489 lb)
External source of data erb
Source of data Handbuch VDRG 1967/1968
