Palcromat 728T

Palcromat 728T; Telefunken (ID = 2430427) Television

Palcromat 728T; Telefunken (ID = 2431141) Television

Palcromat 728T; Telefunken (ID = 2431142) Television

Palcromat 728T; Telefunken (ID = 2431143) Television

Palcromat 728T; Telefunken (ID = 2431144) Television
Palcromat 728T; Telefunken (ID = 845054) Television Palcromat 728T; Telefunken (ID = 1318816) Television
Palcromat 728T; Telefunken (ID = 302918) Television Palcromat 728T; Telefunken (ID = 845053) Television
Palcromat 728T; Telefunken (ID = 1318817) Television Palcromat 728T; Telefunken (ID = 1517503) Television
Palcromat 728T; Telefunken (ID = 1517504) Television Palcromat 728T; Telefunken (ID = 1517505) Television
Use red slider bar for more.
Palcromat 728T; Telefunken (ID = 845054) Television
Telefunken: Palcromat 728T [Television] ID = 845054 933x720
Select picture or schematic to display from thumbnails on the right and click for download.
For model Palcromat 728T, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Telefunken Report '67/68

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1967 Category: Television Receiver (TV) or Monitor
Valves / Tubes 14: PL509 PY500 GY501 PL508 PC92 PCL200 PD500 EF80 PCL86 PCF802 A63-11X
Semiconductors (the count is only for transistors) 33:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Palcromat 728T - Telefunken Deutschland TFK,
Notes

Telefunken PALcromat 728T;
63 cm PAL TV mit elektronischer Diodenabstimmung, VHF/UHF-Tuner Typ MT-500 nach B/G, 73 Dioden, erstes Color Einheitschassis, manche Röhren mehrfach bestückt.
Ausführungen in Nußbaum hell matt oder Teakholz, RGB Aussteuerung mit 3 Farbendstufen, lieferbar ab Mitte Oktober 1967.

Schaltplan siehe Telefunken PALcolor 718 T  ID = 210859

Mentioned in Funkschau (Heft 19 1967 & (D) Telefunken Report '67/68)
