Picnic 3391; Telefunken (ID = 1833236) Radio
Telefunken: Picnic 3391 [Radio] ID = 1833236 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Picnic 3391, Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH:
Antenne nicht orig. UKW bis 104 MHz, Modell Picnic 3391

Country:  Germany
Manufacturer / Brand:  Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH
Year: 1962/1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: OC615 OC615 AF105 AF105a AF105 OC602 AC122 AC117 AC117 OA172 OA174
Main principle Superheterodyne (common); ZF/IF 460/6750 kHz; 3 AF stage(s)
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / D: 5 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Picnic 3391 - Telefunken Deutschland TFK,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 311 x 181 x 93 mm / 12.2 x 7.1 x 3.7 inch
Notes

Lautsprecher: 130 x 75 mm.

Nachfolgemodell des Telefunken Picnic 3291

Änderungen: UKW  87,5-104 MHz statt 87,5-100 MHz
NF-Treibertransistor T202: AC122 statt OC604
NF-Endstufentransistoren: nur noch AC117 statt AC106 oder AC117

Price in first year of sale 320.00 DM

Model page created by Egon Strampe. See "Data change" for further contributors.
