Tesla 51; Radio Industrija (ID = 1350543) Radio
Radio Industrija: Tesla 51 [Radio] ID = 1350543 930x727
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tesla 51, Radio Industrija Nikola Tesla;Beograd

Country:  Yugoslavia
Manufacturer / Brand:  Radio Industrija Nikola Tesla;Beograd
Year: 1951 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH42 EAF42 EL41 EZ40
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Tesla 51 - Radio Industrija Nikola Tesla;
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes Sensitivity to antenna:Short wave 100-150uV, Broadcast 50-60uV.
Short wave 18,75-6MHz, Broadcast 1500-500kHz.
Loudspeaker: 8 ohm
Literature/Schematics (1) Opravka radio aparata II.izdaja (ing. Velimir Mesaroš)

Model page created by Marko Karlin. See "Data change" for further contributors.
