Saturn 348

Saturn 348; TO-R Radio A/S; Vanl (ID = 2516886) Radio Saturn 348; TO-R Radio A/S; Vanl (ID = 2516887) Radio
Saturn 348; TO-R Radio A/S; Vanl (ID = 2516888) Radio Saturn 348; TO-R Radio A/S; Vanl (ID = 2516889) Radio
Saturn 348; TO-R Radio A/S; Vanl (ID = 2517406) Radio
Use red slider bar for more.
Saturn 348; TO-R Radio A/S; Vanl (ID = 2516886) Radio
TO-R Radio A/S; Vanl: Saturn 348 [Radio] ID = 2516886 1280x720
Select picture or schematic to display from thumbnails on the right and click for download.
For model Saturn 348, TO-R Radio A/S; Vanløse

Country:  Denmark
Manufacturer / Brand:  TO-R Radio A/S; Vanløse
Brand

Tor
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH21 UF21 UF21 UBL21 UM4 UY21
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Saturn 348 - TO-R Radio A/S; Vanløse
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Dual scale.
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from TO-R Radio A/S; Vanløse
Here you find 74 models, 63 with images and 44 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
