- Country
- Italy
- Manufacturer / Brand
- Trans Continents (Prandoni); Milano, Treviglio
- Year
- 1956/1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 116268
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 110-220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: PD47 - Trans Continents Prandoni;
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 430 x 280 x 210 mm / 16.9 x 11 x 8.3 inch
- Source of data
- Guida Pratica Antique Radio (1) 1999
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
