R-1000; Trio-Kenwood (ID = 74373) Amateur-R

Trio-Kenwood: R-1000 [Amateur-R] ID = 74373 933x466

Select picture or schematic to display from thumbnails on the right and click for download.

For model R-1000, Trio-Kenwood Electronic Inc.; Komagane

Country:

Japan

Manufacturer / Brand:

Trio-Kenwood Electronic Inc.; Komagane

alternative name

Trio Corp.

Brand

Jennen

Year: 1979–1985 ?

Category: Amateur-Receiver (amateur bands, may include broadcast bands)

Semiconductors (the count is only for transistors)

64:

Main principle	to an article Superhet, double/triple conversion; ZF/IF 48000/455 kHz
Wave bands	Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage	Alternating Current supply (AC) / 100-240 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out	1.5 W (unknown quality)
from Radiomuseum.org	Model: R-1000 - Trio-Kenwood Electronic Inc.;
Material	Metal case
Shape	Tablemodel, with any shape - general.
Dimensions (WHD)	300 x 115 x 218 mm / 11.8 x 4.5 x 8.6 inch
Notes	Kenwood Receiver R-1000. Covering 200-30000 kHz; Modes: SSB, CW, AM; with timer/clock function; external 12-V-Power-Supply possible.
Net weight (2.2 lb = 1 kg)	5.5 kg / 12 lb 1.8 oz (12.115 lb)
Price in first year of sale	1'090.00 DM
Source of data	Shortwave Receivers - Past & Present (3rd ed.)
Mentioned in	Funkschau (Heft 13 /Juni 1981 Seite 73 ff Betriebserprobung)

Model page created by Martin Bösch. See "Data change" for further contributors.

All listed radios etc. from Trio-Kenwood Electronic Inc.; Komagane
Here you find 755 models, 676 with images and 204 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of a member from D

Collection of Heinz Schmidt (D)

Collection of Bryce Ringwood (ZA)

Collection of Martin Bösch (CH)

Collection of Christopher Morrison (CH)

Collection of Bernhard Siegel (D)

Forum contributions about this model

Trio-Kenwood: R-1000

Threads: 1 | Posts: 1

Hits: 2213 Replies: 0

KENWOOD R-1000-Empfänger

Joachim Röhling
14.Dec.07

KENWOOD R-1000-Empfänger

Hallo Radiofreunde,

wer kann mir bitte helfen? Ich besitze einen KENWOOD R-1000 Nachrichtenempfänger. Der Vorbesitzer hat die drei Klemmanschlüsse links (rot-schwarz-rot), warum auch immer, entfernt und gegen andere Anschlüsse getauscht. Ich möchte das Gerät wieder in den Originalzustand bringen und suche daher diesen Klemmensatz.

Hat jemand zufällig so einen übrig oder weiß jemand, wo ich ihn erwerben kann?

Bitte sehen Sie auch das anliegende Foto!

Danke im voraus!

Joachim Röhling
