Report-L 4000

Report-L 4000; Uher Werke; München (ID = 204312) R-Player

Report-L 4000; Uher Werke; München (ID = 204314) R-Player

Report-L 4000; Uher Werke; München (ID = 204315) R-Player

Report-L 4000; Uher Werke; München (ID = 204316) R-Player

Report-L 4000; Uher Werke; München (ID = 1607026) R-Player

Report-L 4000; Uher Werke; München (ID = 1607027) R-Player
Report-L 4000; Uher Werke; München (ID = 2012136) R-Player Report-L 4000; Uher Werke; München (ID = 2258629) R-Player
Report-L 4000; Uher Werke; München (ID = 153665) R-Player Report-L 4000; Uher Werke; München (ID = 153666) R-Player
Report-L 4000; Uher Werke; München (ID = 153667) R-Player Report-L 4000; Uher Werke; München (ID = 30174) R-Player
Report-L 4000; Uher Werke; München (ID = 30175) R-Player Report-L 4000; Uher Werke; München (ID = 179851) R-Player
Report-L 4000; Uher Werke; München (ID = 300773) R-Player Report-L 4000; Uher Werke; München (ID = 300774) R-Player
Use red slider bar for more.
Report-L 4000; Uher Werke; München (ID = 2012136) R-Player
Uher Werke; München: Report-L 4000 [R-Player] ID = 2012136 1400x828
Select picture or schematic to display from thumbnails on the right and click for download.
For model Report-L 4000, Uher Werke; München

Country:  Germany
Manufacturer / Brand:  Uher Werke; München
Year: 1965/1966 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 17: OC305 OC305 OC305 AC151 AC151 AC151 AC153 AC176 BCY51 AC153 AC153 AC153 OC305 OC305 OC305 BFY39 BFY39 AA116 AA116 AA116 ZG3,9 ZL7
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Storage and/or dry batteries / 5 × 1,5; 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Report-L 4000 - Uher Werke; München
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 270 x 85 x 215 mm / 10.6 x 3.3 x 8.5 inch
Notes

Zweispur-Mono;
Bandgeschwindigkeiten:
2,4/4,75/9,5/19 cm/s; Spulen-Ø 13 cm.
Externe Stromversorgung möglich.
Original-Einbaunetzteil (optional): Z124.

Bestückung NF-Teil: 9 Transistoren

Bestückung Motorregelung: 8 Transistoren, 3 Dioden und 2 Zenerdioden

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Collectors' prices
External source of data erb
Source of data Handbuch VDRG 1965/1966 / Radiokatalog Band 2, Ernst Erb
Mentioned in Handbuch RFP 1965/66 S.438, Thiele
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Uher Werke; München
Here you find 331 models, 301 with images and 165 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






rmXorg
