For model Report Stereo 4200 IC, Uher Werke; München

Country:  Germany
Manufacturer / Brand:  Uher Werke; München
Year: 1972–1975 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 20: AC151 AC153KVII BC212 BC238 BC308 BC384
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Dry Batteries / 5 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Report Stereo 4200 IC - Uher Werke; München
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 285 x 95 x 227 mm / 11.2 x 3.7 x 8.9 inch
Notes ICs: 2.
Zweispur-Stereo; Bandgeschwindigkeiten: 2,4/4,75/9,5/19 cm/s; Spulen-Ø: 13 cm; Übertragungsbereich bei 2,4 cm/s: 35-4500 Hz, bei 19 cm/s: 35-20000 Hz; NF-Verstärker mit 2 Endstufen je 0,8 W; Stromversorgung auch durch dryfit-Akku Z212 oder NC-Akku Z214 oder 6-V-/12-V-Autobatterie; Netzbetrieb mit Netz-/Ladegerät Z124 möglich.
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Price in first year of sale 816.00 DM
External source of data Erb
Source of data Handbuch VDRG 1972/1973 / Radiokatalog Band 2, Ernst Erb
