- Country
- Belgium
- Manufacturer / Brand
- Ultra Electric Belge; Bruxelles
- Year
- 1950/1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 206224
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 479 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 140; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 105 - Ultra Electric Belge;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 423 x 275 x 220 mm / 16.7 x 10.8 x 8.7 inch
- Notes
- Dial lamps: 2x 8024D (6,3V/0,3A).
- Source of data
- - - Data from my own collection
- Author
- Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
