Arrow ; Unknown Europe (ID = 1475981) Ampl/Mixer
Unknown Europe: Arrow [Ampl/Mixer] ID = 1475981 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Arrow, Unknown Europe

Country:  Europe
Manufacturer / Brand:  Unknown Europe
alternative name

Unbekannt Europa
Year: 1965 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 6: ECC82 ECC83 EF86 EL84 EL84 EZ81
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 15 W (unknown quality)
from Radiomuseum.org Model: Arrow - Unknown Europe
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 300 x 165 x 175 mm / 11.8 x 6.5 x 6.9 inch
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)

Model page created by Patrick Marinus. See "Data change" for further contributors.
