Telecraft Piano 59

Telecraft Piano 59 ; Unknown Worldwide (ID = 2355087) Radio Telecraft Piano 59 ; Unknown Worldwide (ID = 2355088) Radio
Telecraft Piano 59 ; Unknown Worldwide (ID = 2355089) Radio Telecraft Piano 59 ; Unknown Worldwide (ID = 2355091) Radio
Telecraft Piano 59 ; Unknown Worldwide (ID = 2355094) Radio Telecraft Piano 59 ; Unknown Worldwide (ID = 2355095) Radio
Telecraft Piano 59 ; Unknown Worldwide (ID = 2355096) Radio Telecraft Piano 59 ; Unknown Worldwide (ID = 2355097) Radio
Use red slider bar for more.
Telecraft Piano 59 ; Unknown Worldwide (ID = 2355087) Radio
Unknown Worldwide: Telecraft Piano 59 [Radio] ID = 2355087 960x655
Select picture or schematic to display from thumbnails on the right and click for download.
For model Telecraft Piano 59, Unknown Worldwide:
This set is of my friend Mr. Giri Tirumala of Bangalore. The set is in excellent condition physically, but electronically it had issues. Restoration took 2 weeks, ECH 81 was bad, lot of Noise, Then all the black capacitors replaced, Filter capacitor replaced inside the cap. The 1 Meter band was totally off and had to struggle to get the connection in Bandswitch. EM 80 is dim, due to aging ! Have to replace Good set for local and SW stations.

Country:  Worldwide
Manufacturer / Brand:  Unknown Worldwide
Year: 1959 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH81 EF89 EBF80 EL84 EM80 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 465 kHz
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Telecraft Piano 59 - Unknown Worldwide
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 22 x 16 x 8.5 inch / 559 x 406 x 216 mm
Notes







Net weight (2.2 lb = 1 kg) 6.2 kg / 13 lb 10.5 oz (13.656 lb)

Model page created by Uday Kalburgi. See "Data change" for further contributors.
