• Country
• Italy

• Manufacturer / Brand
• Vega, BP Radio, Brionvega, Brion & Pajetta; Milano, Lissone (MI)

• Year
• 1958–1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 119067

• Number of Tubes
• 7

• Valves / Tubes
• ECC85 UCH81 UF89 UABC80 EM80 UL84 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: FM116 - Vega, BP Radio, Brionvega,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 550 x 320 x 230 mm / 21.7 x 12.6 x 9.1 inch

• Notes
• Serie ANIE MF.

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Price in first year of sale
• 42,000.00 ITL

• Source of data
• Guida Pratica Antique Radio (1) 1999

• Mentioned in
• Catalogo ANIE (1960-61)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
