Year: 1972 ?? | Category: Car Radio, perhaps also + sound player/recorder | ||||
Semiconductors (the count is only for transistors) | Semiconductors present. |
---|
Main principle | Superheterodyne (common) |
---|---|
Wave bands | Broadcast, Long Wave and FM or UHF. |
Details | |
Power type and voltage | Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt |
Loudspeaker | - This model requires external speaker(s). |
Power out | |
from Radiomuseum.org | Model: Hockenheim 70 - Voxson F.A.R.E.T., Roma |
Material | Metal case |
Shape | Chassis only or for «building in» |
Model page created by Alessandro De Poi. See "Data change" for further contributors.
All listed radios etc. from Voxson F.A.R.E.T., Roma
Here you find 147 models, 122 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
Hits: 1552 Replies: 0
voxson: 70; Hockenheim
|
|
Pietro Lanza
28.Feb.15 |
1
L' informazione che voglio dare è quella relativa allo schema elettrico di questa autoradio, e cioe: lo schema elettrico di questa autoradio è quello che nel sito di Radiomuseum è pubblicato come "Car Radio3002 FM Voxson Modello inviato da Eduard Abfalterer . Verificato durante un intervento di manutenzione , da me effettuato, sull'autoradio Hockenheim 70. Saluti |
