Junior 70 3001

Junior 70 3001; Voxson F.A.R.E.T., (ID = 1231344) Car Radio Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283217) Car Radio
Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283218) Car Radio Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283219) Car Radio
Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283220) Car Radio Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283221) Car Radio
Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283222) Car Radio Junior 70 3001; Voxson F.A.R.E.T., (ID = 1283380) Car Radio
Use red slider bar for more.
Junior 70 3001; Voxson F.A.R.E.T., (ID = 1231344) Car Radio
Voxson F.A.R.E.T.,: Junior 70 3001 [Car Radio] ID = 1231344 500x323
Select picture or schematic to display from thumbnails on the right and click for download.
For model Junior 70 3001, Voxson F.A.R.E.T., Roma

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1970 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 7: BF233 BF235 BF233 BC208 BC313 AD161 AD162
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios)
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Junior 70 3001 - Voxson F.A.R.E.T., Roma
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 90 x 36 x 110 mm / 3.5 x 1.4 x 4.3 inch
Notes Two variants were produced with the same model identification: The first with only Medium Wave (3001); the second with Medium and Long Wave (3002).
Net weight (2.2 lb = 1 kg) 0.340 kg / 0 lb 12 oz (0.749 lb)

Model page created by Leonardo Mureddu. See "Data change" for further contributors.
