Junior 901; Voxson F.A.R.E.T., (ID = 2134926) Car Radio
Voxson F.A.R.E.T.,: Junior 901 [Car Radio] ID = 2134926 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Junior 901, Voxson F.A.R.E.T., Roma

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1973 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 7: AF116 AF116 AF116 AF116 BC113 BC119 AD149 OA91 OA91 OA91
Main principle Superhet with RF-stage; ZF/IF 460 kHz; 3 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Junior 901 - Voxson F.A.R.E.T., Roma
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 88 x 38 x 122 mm / 3.5 x 1.5 x 4.8 inch
Notes NF-Leistung: 2 W, Variometer
Source of data -- Collector info (Sammler)
Literature/Schematics (1) Antique Radio Magazine n.67, June-July 2005, page 10. Written in Italian.

Model page created by Urs Gloor. See "Data change" for further contributors.
