Sebring 911; Voxson F.A.R.E.T., (ID = 669068) Car Radio
Voxson F.A.R.E.T.,: Sebring 911 [Car Radio] ID = 669068 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sebring 911, Voxson F.A.R.E.T., Roma

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1963 ?? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 9: AF116 AF116 AF116 AF116 AF116 AC126 AC128 2N376 2N376 OA79 OA79
Main principle Superhet with RF-stage; ZF/IF 460 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Sebring 911 - Voxson F.A.R.E.T., Roma
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 187.5 x 53 x 161 mm / 7.4 x 2.1 x 6.3 inch
Notes Sintonia manuale e 5 stazioni selezionabili tramite altrettanti tasti. 5 Fixsender, NF-Leistung: 2 W, Variometer
Net weight (2.2 lb = 1 kg) 2.140 kg / 4 lb 11.4 oz (4.714 lb)
Source of data -- Collector info (Sammler)
Literature/Schematics (1) Antique Radio Magazine n.67, June-July 2005, page 10. Written in Italian.
Literature/Schematics (4) Bollettino Tecnico Voxson n. 575

Model page created by Urs Gloor. See "Data change" for further contributors.



All listed radios etc. from Voxson F.A.R.E.T., Roma
Here you find 147 models, 122 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
