Silverstone 922

Silverstone 922; Voxson F.A.R.E.T., (ID = 724552) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093937) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093942) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093945) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093950) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093953) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093957) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093960) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093963) Car Radio

Silverstone 922; Voxson F.A.R.E.T., (ID = 1093985) Car Radio
Use red slider bar for more.
Silverstone 922; Voxson F.A.R.E.T., (ID = 724552) Car Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Italy
Manufacturer / Brand:  Voxson F.A.R.E.T., Roma
Year: 1973 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 21: AF116 SE4002 OC72 AC126 AC128 2N376 OA79
Main principle Superheterodyne (common); ZF/IF 460 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Silverstone 922 - Voxson F.A.R.E.T., Roma
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 187.5 x 53 x 161 mm / 7.4 x 2.1 x 6.3 inch
Notes 5 Fixsender, automatischer Suchlauf, Variometer.
Halbleiter pro Typ 1x gelistet.
Net weight (2.2 lb = 1 kg) 2.320 kg / 5 lb 1.8 oz (5.11 lb)
Source of data -- Collector info (Sammler)
Literature/Schematics (1) Antique Radio Magazine n.67, June-July 2005, page 10. Written in Italian.

Model page created by Urs Gloor. See "Data change" for further contributors.



All listed radios etc. from Voxson F.A.R.E.T., Roma
Here you find 147 models, 122 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
