Sintonizzatore MW/LW/FM Stereo 8 Cassette Deck
Use red slider bar for more.
Voxson F.A.R.E.T.,: Sintonizzatore MW/LW/FM Stereo 8 Cassette Deck [Radio] ID = 2083392 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1975 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Broadcast, Long Wave and FM or UHF. |
| Details | Special Tape or Cassette-Format |
| Power type and voltage | Alternating Current supply (AC) / 110; 130; 220; 240 Volt |
| Loudspeaker | - This model requires external speaker(s). |
| Power out | 24 W (unknown quality) |
| from Radiomuseum.org | Model: Sintonizzatore MW/LW/FM Stereo 8 Cassette Deck - Voxson F.A.R.E.T., Roma |
| Material | Plastics (no bakelite or catalin) |
| Shape | Tablemodel, slant panel. |
| Dimensions (WHD) | 380 x 170 x 350 mm / 15 x 6.7 x 13.8 inch |
| Notes | VOXSON Sintonizzatore MW/LW/FM Stereo 8 Cassette Deck - controllo volume - bilanciamento - toni alti - toni bassi - commutatore Power - speaker off/on - A.F.C. - selector program 1/2/3/4 - n. 5 stazioni FM preselector - lampadina segnale FM/ stereo FM - scala MW/LW ed FM separate - ingresso Phono - ingresso Aux - n. 2 uscite per cuffia - potenza uscita: 12 + 12 watt - impedenza 8/16 Ω. Made in Italy |
| Net weight (2.2 lb = 1 kg) | 12.5 kg / 27 lb 8.5 oz (27.533 lb) |
Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
