Sonar GN104-SR

• Country
• Italy

• Manufacturer / Brand
• Voxson, FARET (F.A.R.E.T.); Roma

• Year
• 1974 ??

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 206642

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 24

• Semiconductors
• BC109 BC113 BC108 AC188 AF116 BC119 AD149 OA91

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Details
• Special Tape or Cassette-Format

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 13,5 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Sonar GN104-SR - Voxson, FARET F.A.R.E.T.; Roma

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 150 x 53 x 187.5 mm / 5.9 x 2.1 x 7.4 inch

• Notes

• L'apparecchio Sonar GN104-SR ha tutte le caratteristiche del giranastri GN103-S, in più contiene un radioricevitore a due gamme d'onda, OL ed OM con sintonia ad induttori variabili.
  Apparecchio per i nastri Stereo 8 da installare su autoveicoli.
  Possibilità di funzionare con positivo o negativo a massa.

  Tutti i semiconduttori sono elencati uno per tipo: 24 Transistor e 5 Diodi.

  La versione per l'estero ha una media frequenza di 452 kHz.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• -- Schematic (Schemario Radio Autoradio Mangianastri edizioni "Il Rostro" marzo 1971.)
