• Year
  • 1940 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 64876
    • alternative name: Templeton

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / 117 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 0-549 - Warwick Mfg. Corp., Chicago
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 10.75 x 7.25 x 7 inch / 273 x 184 x 178 mm
  • Notes
  • Built in loop antenna. Broadcasts from 535 to 1740 kc.

  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 12 = ca. 1941 and before
  • Literature/Schematics (1)
  • Riders 12-3
  • Literature/Schematics (3)
  • Clarion Folder.
