Piccolo 1941

Piccolo ; Watt Radio; Torino (ID = 221475) Radio

Piccolo ; Watt Radio; Torino (ID = 250524) Radio
Piccolo ; Watt Radio; Torino (ID = 1306474) Radio Piccolo ; Watt Radio; Torino (ID = 675609) Radio
Piccolo ; Watt Radio; Torino (ID = 1306482) Radio Piccolo ; Watt Radio; Torino (ID = 1306484) Radio
Use red slider bar for more.
Piccolo ; Watt Radio; Torino (ID = 1306474) Radio
Watt Radio; Torino: Piccolo [Radio] ID = 1306474 850x756
Select picture or schematic to display from thumbnails on the right and click for download.
For model Piccolo 1941, Watt Radio; Torino

Country:  Italy
Manufacturer / Brand:  Watt Radio; Torino
Year: 1941/1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8 6K7 6Q7 35L6 35Z4
Main principle Superheterodyne (common); ZF/IF 460 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 125; 140; 160; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Piccolo [1941] - Watt Radio; Torino
Material Wooden case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 250 x 180 x 130 mm / 9.8 x 7.1 x 5.1 inch
Notes

Mobile in impasto di sughero e legno. Anche variante solo OM. Con maniglia di trasporto.
Corky wooden case. Also variant with broadcast band only. With carrying handle.

Autotrasformatore: Telaio collegato alla rete elettrica. Non tutti i casi sono dichiarati poichè spesso chi propone il modello non lo può sapere.

Source of data Guida Pratica Antique Radio III (2000)
Literature/Schematics (1) Collezione di Schemi, Scuola Radio Elettra 1953
Literature/Schematics (2) -- Schematic (Il Manuale del Radiomeccanico G.B. Angeletti – Radio Industria – 1945)

Model page created by Pietro Gallia. See "Data change" for further contributors.
