Fox 364W-3

Fox 364W-3; Wega, (ID = 130049) Radio

Fox 364W-3; Wega, (ID = 130050) Radio
Fox 364W-3; Wega, (ID = 67778) Radio Fox 364W-3; Wega, (ID = 66396) Radio
Fox 364W-3; Wega, (ID = 401322) Radio Fox 364W-3; Wega, (ID = 564053) Radio
Fox 364W-3; Wega, (ID = 564054) Radio Fox 364W-3; Wega, (ID = 564055) Radio
Use red slider bar for more.
Fox 364W-3; Wega, (ID = 67778) Radio
Wega,: Fox 364W-3 [Radio] ID = 67778 640x493
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fox 364W-3, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1950/1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH11 EBF11 ECL11 AZ11
Main principle Superheterodyne (common); ZF/IF 473 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110, 130, 155, 220, 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: Fox 364W-3 - Wega, Württembergische Radio-
Material Bakelite case
Dimensions (WHD) 420 x 280 x 194 mm / 16.5 x 11 x 7.6 inch
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Source of data Radiokatalog Band 1, Ernst Erb


All listed radios etc. from Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
Here you find 658 models, 579 with images and 380 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
